Work Height - 38’ (11.58 m)
Raised Platform Height - 32’ (9.75 m)
Lowered Platform Height - 54” (1.37 m)
Overall Width - 69.5” (1.76 m)
Overall Length - 107” (2.72 m)
Stowed Height (Rails Up) - 99” (2.51 m)
Stowed Height (Rails Down) - 69” (1.75 m)
Platform Width (Inside Dimension) - 56” (1.42 m)
Platform Length (Inside Dimension) - 96” (2.44 m)
Extension Deck - 5’ (1.52 m)
Ground Clearance - 8” (0.20 m)
Wheelbase - 80.5” (2.04 m)
Weight - 7,590 lbs (3,443 kg)
Gradeability - 40%
Turning Radius (Inside) - 60” (1.52 m)
Turning Radius (Outside) - 156” (3.96 m)
Lift Time (With Rated Load) - 39 sec
Lower time (With Rated Load) - 36 sec
Drive Speed (Stowed) - 3.8 mph (6.1 km/h)
Drive Speed (Raised) - 0.4 mph (0.6 km/h)
Maximum Drive Height - Full Height
Capacity (Overall) - 1,000 lbs (454 kg)
Distributed Capacity (Main Platform) - 700 lbs (318 kg)
Distributed Capacity (Extension Deck) - 300 lbs (136 kg)
Local Floor Load (With Rated Load) - 216 psi (1,500 kPa)
Overall Floor Load (With Rated Load) - 200 psf (976 kg/m2 )
Maximum # of persons - 4
Wind rating - Up to 28 mph (12.5 m/s)
Engine - Kubota Gas/Propane
Fuel Tank - 23 gal (87 L)
Hydraulic Reservoir - 23 gal (87 L)
Outrigger Leveling (Front to Back / Side to Side) - 5° / 8°
Tire Type - Foam-Filled
Tire Size - 26 x 12
